EXPLORER BALANCES
EN-15
3.4 Overview of Parts and Features
– Non-Draft Shield Models
Top View
Rear View
Bottom View
Side View
Figure 3-2. Explorer Base
Illuminated
Level
Indicator
Touchless
Sensors
Touchless
Sensors with
Indicator Lights
Type label (Far side)
(M, N models only)
Data label
Terminal cable
storage clips
Lock switch
Weigh
Below
Access
Foot; Non-
Adjustable
Leveling
Thumbwheels
Power
Connection
