Ohaus EXPLORER PRECISION HIGH CAPACITY BALANCES Manual - Manual (Page 135)

EXPLORER BALANCES EN-133
TABLE 9-9. SPECIFICATIONS
MODEL EX12001 EX24001 EX35001
Max 12000 g 24000 g 35000 g
Readability d 0.1 g
Repeatability (std. dev.) 0.1 g
Linearity +0.2 g
Span Calibration Points
3000g, 5000g, 10000g,
12000g
10000g, 15000g,
20000g, 24000g
10000g, 20000g,
30000g, 35000g
Weighing units
kilogram, carat, pennyweight,
grain, pound, ounce, troy ounce
Applications
Weighing, Parts Counting, Percent Weighing, Check Weighing,
Dynamic Weighing, Filling, Totalization, Formulation, Differential
Weighing, Peak Hold, Density Determination, Ingredient Costing,
Statistical Quality Control
Stabilization time (typical) Within 1 second
Sensitivity Temperature Drift (PPM/K) 5
Typical Minimum Weight 210g
Display Full-Color VGA Graphic LCD
Display size 5.7 in / 14.5 cm (diagonal)
Backlight White LED
Controls 2-wire resistive touch screen
Communication RS-232, USB
Power supply Power Input: 100-240 V~ 0.5A 50/60 Hz
Platform size
377 x 311 mm
14.8 x 12.2 in
Terminal Housing dimensions
(W x D x H) 195 x 155 x 68 mm
7.7 x 6.1 x 2.7 inch
Base Housing dimensions
(W x D x H) 377 x 311 x 120 mm
14.8 x 12.2 x 4.7 inch
Assembled dimensions
(W x D x H) 442 x 311 x 120 mm
17.4 x 12.2 x 4.7 inch
Net weight 10 kg / 22 lb
Shipping weight 12 kg / 26.5 lb
Note: Default Calibration weights shown in Bold
