Ohaus EXPLORER PRECISION HIGH CAPACITY BALANCES Manual User Manual
Page 16
EN-14
EXPLORER BALANCES
I/O Settings:
Touch to view remote I/O Settings.
Information:
Touch to view list of topics.
3.3
Overview of Parts and Features
–Draft Shield Models
Top View
Rear View
Bottom View
Side View
Figure 3-1. Explorer Balance (including Automatic draftshield door and ExCal models)
Leveling
Thumbwheels
Data label
Terminal cable
storage clips
Lock switch
Weigh
Below
Access
Foot; Non-
Adjustable
Type label (Far side)
(M, N models only)
Touchless
Sensors
Power
Connection
Draft Shield
Light
Illuminated
Level
Indicator
(hidden)
Touchless
Sensors with
Indicator Lights
