EN-132 EXPLORER BALANCES
TABLE 9-8. SPECIFICATIONS
MODEL EX223/E EX423/E EX2202/E EX4202/E EX6202/E EX6201/E
Capacity 220 g 420 g 2200 g 4200 g 6200 g 6200 g
Readability d 0.001 g 0.001 g 0.01 g 0.01 g 0.01 g 0.1 g
Repeatability 0.001 g 0.001 g 0.01 g 0.01 g 0.01 g 0.1 g
Linearity + 0.002 g + 0.002 g + 0.02 g + 0.02 g + 0.02 g + 0.2 g
Span
Calibration
Points 100g,
150g,
200g
200g,
300g,
400g
1000g,
2000g
2000g, 3000g,
4000g
3000g,
4000g,
5000g,
6000g
3000g,
4000g,
5000g,
6000g
Calibration External Calibration
Weighing units
Baht, carat, grain, gram, kilogram, mesgal, momme, Newton, ounce, pennyweight,
pound, Tael (Hong Kong), Tael, (Singapore), Tael (Taiwan), tical, tola, troy ounce,
custom (3)
Applications
Weighing, Parts Counting, Percent Weighing, Check Weighing, Dynamic Weighing,
Filling, Totalization, Formulation, Differential Weighing, Peak Hold, Density
Determination, Pipette Adjustment, Ingredient Costing, Statistical Quality Control
Stabilization
time ≤ 3
seconds
≤ 2 seconds
Sensitivity
Temperature
Drift (PPM/K)
3 3 3 3 3 3
Typical
Minimum
Weight
2.1g 2.1g 21g 21g 21g 210g
Display Full-Color VGA Graphic LCD
Display size 5.7 in / 14.5 cm (diagonal)
Backlight White LED
Controls 4-wire resistive touch screen
Communication RS-232, USB
Balance power
input
12 VDC, 0.5A
Power supply
AC Adapter Input: 100-240 VAC 0.6A 50-60 Hz
AC Adapter Output: 12 VDC 1.5A
Platform size
190 x 200 mm
7.5 x 8.0 in
Terminal
Housing
dimensions
(W x D x H)
195 x 155 x 68 mm
7.7 x 6.1 x 2.7 inch
Base Housing
dimensions
(W x D x H)
230 x 260 x 98 mm
9.1 x 10.2 x 3.9 inch
Assembled
dimensions
(W x D x H)
229 x 391 x 350 mm
9.1 x 15.5 x 13.8 inch
229 x 391 x 98 mm
9.0 x 15.4 x 3.9 inch
Net weight
6.4 kg
14.1 lb
6.4 kg
14.1 lb
4.3 kg
9.5 lb
4.3 kg
9.5 lb
5.0 kg
11.0 lb
5.0 kg
11.0 lb
Shipping
weight 9.2 kg
20.3 lb
9.2 kg
20.3 lb
6.8 kg
15.0 lb
6.8 kg
15.0 lb
7.4 kg
16.3 lb
7.4 kg
16.3 lb
Note: Default Calibration weights shown in Bold
