EXPLORER BALANCES EN-135
9.2 Drawings and Dimensions
Fully assembled dimensions
Figure 9-1. Draft Shield models
Figure 9-2. Non-Draft Shield models
Figure 9-3. EX12001, EX24001 and EX35001 models
15.5 in.
393 mm
3.9 in.
98 mm
9.1 in.
230 mm
9.1 in.
230 mm
13.8 in.
350 mm
15.5 in.
393 mm
14.8 in.
377 mm
4.7 in.
120 mm
17.4 in.
443 mm
12.1 in.
1.9 in.
48 mm
311 mm
