14.1a
Technical specifications and illustrations are without
obligation, subject to modifications. 04.12/06.13
Description Part No.
Extra charge for liquid alarm with flow chamber LS/LA2 at front panel filter FPF-0,1GF 03E3010
Extra charge for mounting a font panel filter FPF+ 04F2100
Extra charge for a filter element for FPF+ (depending on filter element) toƒchoice
Extra charge for liquid alarm sensor LA3 integrated in FPF+ 03E1300
Extra charge for universal filter / aerosol filter CLF.. (depending on filter) toƒchoice
Extra charge for mounting an universal filter / aerosol filter CLF on front plate (max. 2 pcs.) 01G6075
Extra charge for liquid alarm LA1S for universal filter F.-..-D 03E3001
Ballƒvalvesƒforƒtestƒgasƒfeedingƒ(max.ƒ1ƒpc.)
Extra charge for mounting a 3-way ball valve 3L/PV
01G9046
Extra charge for mounting a 5-way ball valve 5L/PV 01G9045
Sampleƒgasƒpumpsƒ(max.ƒ2ƒpcs.)ƒ(onlyƒwithƒelectronicƒcontrollerƒ01G6175)
Extra charge for mounting sample gas pumps N..KPE
01G6070
Extra charge for mounting the sample gas pump N3KPE 01G6125
Extra charge for mounting the sample gas pump N5KPE 01G6130
Extra charge for mounting the sample gas pump N9KPE 01G6135
Flowmeterƒ(max.ƒ4ƒpcs.ƒinƒtotal)ƒandƒflowƒalarmƒ(max.ƒ2ƒpcs.)
Extra charge for mounting a flowmeter FM40 7-70Nl/hr in sample gas outlet
09F4000
Extra charge for mounting a fowmeter FM40 15-150Nl/hr in sample gas outlet 09F4005
Extra charge for mounting a fowmeter FM40 25-250Nl/hr in sample gas outlet 09F4010
Extra charge for mounting a fowmeter FM40 50-500Nl/hr in sample gas outlet 09F4015
Extra charge for flow alarm with forked light barrier FA-20mo 02E3500
Extra charge for second sample gas outlet resp. bypass with flow meter FM40 7-70Nl/hr 01G6200
Extra charge for second sample gas outlet resp. bypass with flow meter FM40 15-150Nl/hr 01G6210
Extra charge for second sample gas outlet resp. bypass with flow meter FM40 25-250Nl/hr 01G6220
Extra charge for second sample gas outlet resp. bypass with flow meter FM40 50-500Nl/hr 01G6230
Electronicƒcontrollers
Extra charge for electronic controller with collective status alarm
01G6170
Extra charge for single alarm messages (temperature, flow, liquid in the system) inclusive mA-outlet (4-20mA, or 0-20mA on request) for
cooler temperature for external temperature display 01G6175
Externalƒadditionalƒmodulesƒ(onlyƒwithƒelectronicƒcontrollerƒ01G6175)
Extra charge for communication module (only necessary once for all extension modules of the TCU)
01B8620
Extra charge for temperature controller module (2 additional temperature controllers in TCU with 4 relays for excess resp. low temperature
monitoring) for control of solid state relays
For controller parameterization please specify with order which M&C devices should be controlled (type of gas sample probe(s) resp. type and length
of heated sample line(s)). 01B8640
Extra charge for status module for collective alarm message via 1 changeover contact relay and 1 solid state relay for switching of external
sample gas pumps 01B8630
Extra charge for blow back module for programmed control of solenoid valves for blow back of gas sample probes with status monitoring
(measuring/blow back), monitoring of the blow back pressure and control of the sample gas pumps (on/off ) 01B8650
Extra charge for M&C-bus for external modules 01G6180
Carryingƒcaseƒ(onlyƒforƒ19“-version)
Extra charge for aluminium carrying case for portable gas conditioning
01G6250
Temperature controller for heated sample line (only with electronic controller 01G6175)
Extra charge for temperature controller for max. 10m heated sample line, 230V with PT100, with solid state relais and 7-pole plug
01G6190
Bending protection adapter for portable gas conditioning
Extra charge for bending protection for heated sample line DN4/6
01G9060
Extra charge for bending protection for heated sample line DN6/8 01G9061
Options
Order example:
1x 01G6050 + 1 x 01G6060 + 1 x + 1x 93K0150 + 1 x 01G6140 + 1x 04F2100 + 1 x 90F0002 + 1 x 03E1300 + 1 x 03F3005 + 1 x 01G6075 + 1 x 01G6070 + 1 x
01G6130 + 1 x 09F4005 + 1 x 02E3500 + 1 x 01G6210 + 1 x 01G6175 + 1 x 01G9160 =
CSS-VC1, 230V, with heat exchanger out of glass, sample gas connections in the joint plate, built in peristaltic pump SR25.2, built in front panel filter FPF+2T
with integrated liquid alarm sensor LA3, aerosol filter CLF-5/W mounted on front panel, built-in sample gas pump N5KPE, flowmeter FM40 15-150Nl/hr and flow
alarm sensor FA-20mo in the sample outlet, flowmeter FM40 15-150Nl/hr in the bypass, single alarm messages and mA-outlet for external cooling temperature
indication, temperature controller module TCU.
