Gas Conditioning Unit series CSS® Version CSS-VC1 Version CSS-VC2
Part No. 230V 50Hz 01G6050 01G6055
Part No. 115V/50-60Hz 01G6050a 01G6055a
Sample outlet dew point range of adjustment: +2 °C ..... +7 °C, factory setting: +5 °C
Dew point stability at constant conditions < ±0,1 °C
Sample inlet temperature **max. 180 °C
Sample inlet dew point **max.+80 °C
Gas flow rate **max. 250 Nl/hr **max. 2 x 150 Nl/hr
Ambient temperature **+5 °C up to +40 °C
Storage temperature -25 °C up to +65 °C
Pressure 0,7 bar up to 1,4 bar abs.
Total cooling capacity ** max. 144 kJ/hr
Number of gas inlets 1 2
Number of gas outlets 1 2
Condensate outlet 1 2
Medium connections tube connection 4/6 mm
Material of sample contacting parts Heat exchanger : glass, PVDF or stainless steel 1.4571
Tubing and fittings : PTFE, PVDF
Universal filter FP-2T-D : PVDF, FPM, glass, PTFE
Front panel filter FPF-0,1GF : PVDF, glass, FPM
Front panel filter FPF+ : PVDF, glass, FPM
Peristaltic pump SR25.2 : PVDF, Novoprene
®
Liquid particle filter CLF-5/W : PVDF, glass, FPM, PTFE
Sample gas pumps N3/5/9 : PVDF, PTFE, FPM
Flowmeter FM40 : PVDF, glass, FPM, Hastelloy C4
Ball valve 3L/PV and 5L/PV : PVDF, FPM
Ready for operation approx. 10 min.
Power supply 230V 50-60Hz ±10% resp. 115V 50-60Hz ±10%***
Power consumption max. 220VA + max. 300VA for the sample gas pumpfür die Messgaspumpen
Fuse protection 4A t, 5x 20 mm
Electrical connection Cold appliance plug with 2 m of cable
Case protection IP20 EN 60529
Housing protection sheet steel case for 19“- or wall mounting, lacquered RAL 7032
Equipment dimensions (H x W x D) 267,5 mm x 483 mm x 301,5 mm
(portable version : 355 mm x 515 mm x 395 mm)
Electrical equipment standard EN61010
Weight approx. 22 kg
Technical Data
PVDF = Polyvinylidenfluoride
PVC = Polyvinylchloride
FPM = Fluor caoutchouc = Viton ®
PPH = Polypropylene hard
PTFE = Polytetraflourethylene
** Technische Daten mit Max.-Angaben sind unter Berücksichtigung der Gesamtkühlleistung bei 25 °C und einem Ausgangstaupunkt von 5 °C zu bewerten.
*** 115V/50Hz sample gas pump as feature artticle possible
Description Part No.
Heatƒexchangersƒandƒhousingƒversion
Extra charge for gas connections directly at one heat exchanger
01G6062
Extra charge for heat exchanger ECM-1 out of glass for CSS-VC1, sample gas connections at the heat exchanger 93K0140
Extra charge for heat exchanger ECM-1 out of stainless steel SS316Ti for CSS-VC1, sample gas connections at the heat exchanger 93K0160
Extra charge for heat exchanger ECM-1 out of PVDF for CSS-VC1, sample gas connections at the heat exchanger 93K0170
Extra charge for gas connections directly at two heat exchangers 01G6063
Extra charge for heat exchanger ECM-2 out of glass for CSS-VC2, sample gas connections at the heat exchanger 97K0100
Extra charge for heat exchanger ECM-2 out of stainless steel SS316Ti for CSS-VC2, sample gas connections at the heat exchanger 97K0115
Extra charge for heat exchanger ECM-2 out of PVDF for CSS-VC2, sample gas connections at the heat exchanger 97K0110
Extra charge for gas connections of one heat exchanger in the joint plate for e.g. 19“ mounting 01G6060
Extra charge for heat exchanger ECM-1 90° out of glass for CSS-VC1, sample gas connections in the joint plate for e.g. 19“ mounting 93K0150
Extra charge for heat exchanger ECM-1 out of PVDF for CSS-VC1, sample gas connections in the joint plate for e.g. 19“ mounting 93K0170
Extra charge for gas connections of two heat exchangers in the joint plate for e.g. 19“ mounting 01G6061
Extra charge for heat exchanger ECM-2 90° out of glass for CSS-VC1, sample gas connections in the joint plate for e.g. 19“ mounting 97K0150
Extra charge for heat exchanger ECM-2 out of PVDF for CSS-VC1, sample gas connections in the joint plate for e.g. 19“ mounting 97K0110
Peristalticƒpumpsƒforƒcondensateƒremovalƒ(max.ƒ2ƒpcs.)
Extra charge for mounting a peristaltic pump SR25.2 for condensate removal, completely flexible tubed (one per gas path necessary)
01G6140
Filtersƒ(max.ƒ2ƒpcs.ƒfrontƒpanelƒfiltersƒandƒ2ƒpcs.ƒuniversalƒfiltersƒresp.ƒaerosolƒfilters)ƒandƒliquidƒalarm
Extra charge for mounting of front panel filter FPF-0,1GF
04F1000
Options
