5.2
Technical specifications and illustrations are without
obligation, subject to modifications. 04.06/04.08
Part no. 20 S 4300 : compl. set critical orifice a-g , injector orifice II , orifice seals
control panel -S, -S1 incl. wall mounting housing optional available: -S-G, -S1-G.
Other versions on request.
Part No. Type M&C gas sample dilution probe SP2006-H/DIL .... with orfice ”e“ for dillution ratio 30 : 1 standard
SP2006-H/DIL dilution probe 180 °C without ball valve upstream of the filter element
SP2006-H280/DIL dilution probe 280 °C without ball valve upstream of the filter element
SP2006-H/DIL-VA dilution probe 180 °C with heated manual operated ball valve upstream of the filter element
SP2006-H/DIL-B dilution probe 180 °C with bypass injector and bypass gas to the vent
SP2006-H/DIL-BR dilution probe 180 °C with bypass injector and bypass gas recirculation
SP2006-H/DIL-BBF dilution probe 180 °C with blow back via the filter element
SP2006-H/DIL-BB dilution probe 180 °C with blow back via the filter chamber
SP2006-H/DIL-I dilution probe 180 °C with pneumatic isolation valve to shut off the sample outlet from the filter chamber
SP2006-H/DIL-BR-I dilution probe 180 °C with bypass injector, bypass gas recirculation and isolation valve to shut off the sample out-
let from the filter chamber
SP2006-H/DIL-BR-BB dilution probe 180 °C with bypass injector, bypass gas recirculation and blow back via the filter chamber
SP2006-H/DIL-BR-BBF dilution probe 180 °C with bypass injector, bypass gas recirculation and blow back via the filter element
SP2006-H/DIL-BR-VA dilution probe 180 °C with bypass injector, bypass gas recirculation and heated manual operated ball valve up-
stream of the filter element
20S4402 (a) SP2006-H/DIL-2x dilution probe 180 °C with second sample outlet
20S4423 (a) SP2006-H/DIL-B-2x dilution probe 180 °C with bypass injector, bypass gas to the vent and second sample outlet
20S4424 (a) SP2006-H/DIL-BR-2x dilution probe 180 °C with bypass injector, bypass gas recirculation and second sample outlet
20S4250 SP2000H/DIL-S option: control panel with 1 pressure controller, 2 gauges, flowmeter, 2 ball valves
20S4260 SP2000H/DIL-S1 option: control panel with 2 pressure controllers, 3 gauges, flowmeter, 2 ball valves
