M&C TechGroup Germany GmbH • Rehhecke 79 • 40885 Ratingen • Germany
[email protected] • www.mc-techgroup.com • Fon +49 2102 935-0 • Fax +49 2102 935-111
14.5
Technical specifications and illustrations are without
obligation, subject to modifications. 09.95/12.11
Gas Conditioning Unit series PSS ® version PSS-5 version PSS-5/3
Part No. for 230V 50Hz version 01G1100 01G1500
Part No. for 115V 60Hz version 01G1100a 01G1500a
Sample outlet dew point range of adjustment: +2 °C ..... +15 °C, factory setting: +5 °C
Dew point stability at constant conditions < ±0,1 °C
Sample inlet temperature **max. 80 °C optional: **max.180 °C with stainless steel bulkhead union
Sample inlet dew point **max.+80 °C
Gas flow rate **max. 150 Nl/hr **max. 350 Nl/hr
Ambient temperature **+5 °C up to +40 °C
Storage temperature -25 °C up to +65 °C
Pressure 0,7 bar up to 1,4 bar abs.
Total cooling capacity ** max. 50 kJ/hr max. 90 kJ/hr
Number of gas inlets 1
Number of gas outlets 1 optional: max. 4
Medium connections tube connection 4/6 mm
Material of sample contacting parts stainless steel, glass, PPH, PVC, PVDF, PTFE, Novoprene ® optional: FDM for gas sample line, part no.: 01G9025
Ready for operation approx. 10 min.
Power supply 230V 50Hz or 115V 60Hz
Power consumption max. 240VA; with option temperature controller and heated sample line 230V: max. 1620VA 115V: max. 920VA
Fuse protection 4A t, 5x 20 mm, with option temperature controller: 10A t
Electrical connection Cold appliance plug with 2 m of cable
Case protection IP20 (DIN 40050. IEC 529)
Housing portable aluminium-frame case
Housing dimensions 440 mm x 540 mm x 255 mm (H x W x D)
Electrical equipment standard EN61010
Weight approx. 18,5 kg approx. 20,0 kg
Options Type Part No
Further sample gas outlet Parallel samplegas outlet, tubing via T-piece on lateral PVDF bulkhead fitting, DN4/6, max. 4 pieces 01G9065
Flowmeter, max. 4 pieces FM40 7-70 l/hr air, mounted in sample gas outlet
FM40 15-150 l/hr air , mounted in sample gas outlet
FM40 25-250 l/hr air , mounted in sample gas outlet
FM40 50-500 l/hr air, mounted in sample gas outlet 01G9070
01G9075
01G9080
01G9085
Fittings out of PVDF Fittings out of PVDF instead of PP and 3m FPM sample tube DN4/6 01G9025
Sample tube Sample tube out of Kanthal ® ø 6 mm, length 1 m, sampling temperature max. 1300 °C 01G9030
Liquid alarm Liquid alarm LA 1/1.4, consisting of: liquid alarm sensor LA1, controller LA1.4, filter glass
F120G-D with GL connection incl. mountage/wiring. In case of condensate inrush,
the sample gas pump is automatically switched of. 01G9035
3-way ball valve 3L/PV-1 for switching over from test gas to sample gas, in the inlet of the sample gas
conditioning unit, mounted with mounting brackets, fitting PVDF 01G9046
5-way ball valve 5L/PV-1 for switching over from test gas to sample gas, in the inlet of the sample gas
conditioning unit, mounted with mounting brackets, fitting PVDF 01G9045
Electronic temperature controller
for max. 12 m heated sample line
100W/m 701 control range 0-200 °C, inlet PT100, power 230V 50Hz,
Contact capacity 250V
AC max. 10A, completely mounted incl. 7-pin plug 10A
01G9055
Electronic temperature controller
for max. 6 m heated sample line 100W/m 701 control range 0-200 °C, inlet PT100, power 115V 60Hz,
Contact capacity 250V
AC max. 10A, completely mounted incl. 7-pin plug 10A
01G9055a
Connecting adapter DN4/6 for heated
sample line PSS-5 connecting adapter with bending protection for rigid mountage of heated sample line with in-
terchangeable PTFE tube DN4/6, consisting of special Swagelok fitting with 4mm cartridge, material:
SS316Ti. 01G9060
Connecting adapter DN6/8 for heated
sample line PSS-5 connecting adapter with bending protection for rigid mountage of heated sample line with in-
terchangeable PTFE tube DN6/8, consisting of special Swagelok fitting with 6mm cartridge, material:
SS316Ti. 01G9060
Technical Data
PPH = Polypropylene
PTFE = Polytetrafluoroethylene (Teflon ® )
PVC = Polyvinylchloride
PVDF = Polyvinylidenfluoride
** Maximum values in technical data’s must be rated in consideration of total cooling capacity at 25 °C ambient temperature and 5 °C outlet dew point.
Other versions on request.
