11.3
Technical specifications and illustrations are without
obligation, subject to modifications. 03.96/11.06
V3/2-H V3/2-H/PE MV2/2-H MV3/2-H
Part-No. 03V3000 (a)** 03V3010 (a)** 03V1500 (a)** 03V2000 (a)**
Position identification no yes no
Nominal width / C
v
-value DN 7, C
v
1,7 DN 7, C
v
1,7 DN 4, C
v
0,4
Operating pressure max. 30 bar max. 2 bar
Sample gas temperature max. +180 °C
Ambient temperature -25 to +60 °C
Storage temperature -25 to +80 °C
Gas connections tube connectors ø6 mm, optional ø1/4" type Swagelok
Temperature controller capillary thermostat with high temperature limiter and low temperature alarm
integrated in electrical connection box
Operating temperature adjustable from 0 to 180 °C, set at factory to 180 °C
Dial thermometer Indicating range 50 to 250 °C
Low temperature alarm contact alarm point ∆T 30 °C, change over contact, voltage free; contact rating 250V, 3A~, 0,25A=
Position identification change over contact vol-
tage free,
contact rating 250V AC
1A
Power supply solenoid valves 24V DC 15W
Power supply 230V 50Hz, 350VA **optional 115V 60Hz (a)
Electrical connections terminals 4 mm 2 , 2x cable glands PG13 (3x with V3/2-H/PE, MV3/2-H)
Degree of protection / Electrical standard IP 54 EN60529 / EN 61010, EN60519-1
Dimensions 350 x 320 x 150 mm (w x h x d) 350 x 320 x 135 mm (w x h x d)
Weight 7,5 kg 8 kg
Stacknant volume approx. 5 cm 3 approx. 5 cm 3
Materials of sample contacting parts stainless steel 316Ti, PTFE stainless steel 316Ti, FFKM, FPM
Mounting Wall mounting
Technical Data
