2.11
Gas sample probe type SP3110V (up to 185 °C) SP3110 (more than 185 °C)
Option back purge unit type RS RS
Part No. 20S5560 (a)
Power supply 230V 50/60Hz 9W or 115V 50/60Hz 9W (a)
Electrical connection cable 3x1mm 2
Marking
II 2GD EEx m II 135°C
Connection G 1/2”i at the buffer vessel
Max. back purge pressure 6 bar abs.
Volume buffer vessel 2 liters
Ambient temperature -20°C to 60°C
Option 2-way-ball valve in the probe entrance /VA
Part No. 20S9050
Operating temperature -20°C up to 185°C
Option 2/3-way-ball valve in the probe entrance /3VA
Part No. 20S9325
Backflush / Test gas connection 6mm tube
Operating temperature -20°C up to +185°C
Option pneum. drive for ball valve /VA o. /3VA MS1
Part No. 20S9055
Connection control air G1/4” i
Pressure control air 5-10 bar
Option valve for blowback or calibration gas 1/4” /R
Part No. 20S9045
Opening pressure >0,7 bar
Connection 6mm tube
Maximum blow back pressure 6 bar abs.
Maximum operating temperature +185 °C
Option variable calibration gas feeding /R + /CC and /CCF
Part No. 20S9045 + 20S9012
Way of test gas /R/CC = via sample gas outlet or /R/CCF = via probe filter element
Check valve /R check valve 1/4”
Opening pressure >0,7 bar
Connection 6mm tube
Maximum blow back pressure 6 bar abs.
Maximum operating temperature +185 °C
Option high performance blow back valve /BB /BBF
Part No. 20S9008 20S9006
Way of blow back gas via filter chamber via probe filter element
Check valve high performance check valve 3/8”
Opening pressure >0,7 bar
Connection 8mm tube
Maximum blow back pressure 6 bar abs.
Maximum operating temperature 185 °C
Option test gas valve / shut-off valve /C + /I
Part No. 20S9011 + 20S9009
Way of test gas via sample gas outlet with shut-off to the process
Check valve check valve 1/4”
Opening pessure >0,7 bar
Connection 6mm tube
Shut-off valve bellow-type valve with pneumatic drive
Pressure control air 3-10 bar
Connection control air 1/8” NPT i
Option second sample gas outlet /2X
Part No. 20S9015
Connection 1/4” NPT i
Optionƒspunƒglassƒcartridge /FW
Part No. 20S9047 20S9046
Material SS316Ti, Novapress SS316Ti, Graphite
Technical Data
* Standard, ** Option
Technical specifications and illustrations are without
obligation, subject to modifications. 10.04/11.12
