9.1
Technical specifications and illustrations are without
obligation, subject to modifications. 09.96/11.06
Measuring range FM1 FM1-H FM10 FM10-H
Flowmeter types on stock Part No. Part No. Part No. Part No.
10 - 100 l/h Luft 09F1000 09F1100 09F1500 09F1550
25 - 250 l/h Luft 09F1010 09F1510
50 - 500 l/h Luft 09F1020 09F1520
80 - 800 l/h Luft 09F1030 09F1530
Option: 09F9000 for special measuring range and special calibration.
Part Number of the types on stock
Any other execution please order in clear: Flowmeter FM1, 6-60 l/hr air, 20 °C, 1,2 bar
Please specify with order: measuring range: ... l/hr;
medium: .... ;
pressure: ... bar;
temperature: ... °C
e.g. Flowmeter FM10; 7-70 l/hr chlorine; 20 °C; 1,2 bar
* Standard (alternatively)
** Floating ball out of Hastelloy C
Technical Data
Flowmeter FM1 FM1-H FM10 FM10-H
Needle valve in the inlet NO YES
Standard- maximum measures
adjusted on 1,2 bar; 20 °C ..l/hr air:
..l/hr water: types on stock = ___
16 40 60 100 250 500 800
2,5 5 12 25 40 60 100**
Measures ....l/h air at 20 °C; 1,2 bar min. 0,8-8 l/hr; max. 120-1200 l/hr is possible
Scale of measurement 10 : 1
Status of precision 2,5 %
Scale Length of the scale 100 mm, adjusted in l/hr
Pressure max. 4 bar g
Sample temperature, max. +80 °C +150 °C +80 °C +150 °C
Ambient temperature, max. +60 °C +150 °C +60 °C +150 °C
Storage temperature -25 °C to +80 °C
Connections, INLET GL18-ш6* (ш8, ш10) G1/4"i DIN ISO 228/1
Connections, OUTLET GL18-ш6* (ш8, ш10) GL18-ш6* (ш8, ш10)
Method and position of mounting Wall mounting / vertical
Materials of sample contacting parts Borosilicate glass, PTFE Borosilicate glass, PTFE, PEEK
Dimensions, h x w x d 250 x 40 x 40 mm 320 x 40 x 84 mm
Weight 130 g 280 g 300 g 440 g
