Gas sampling and gas conditioning technology 2-1.9.6MD
9 TECHNICAL DATA
Series SP
®
SP35-H1.1 SP35-H2 SP30-H1.1 SP30-H2 SP30-H1.1-V
Temperature sensor Fe-CuNi PT100 2-wire Fe-CuNi PT100 2-wire Fe-CuNi
Temperature controller external
Probe tube length L1 175mm max. 2 m max. 2 m
Sample temperature max. 550 °C
Operating temperature
max. 320°C 200°C 320°C 200°C 320°C
Pre-filter V20-2/30 insitu
filter length
520 mm,

60
mm, filter
porosity 2
μm,
integrated and
heated
Sample gas inlet
connection G3/4"i DIN ISO 228/1 pre-filter with
G1 1/2"i DIN
ISO 228/1
Dust loading max. 2 g/m
3
>2 g/m
3
Probe tube volume 380 ml/m 420 ml
Sample pressure max. 5 bar g
Ambient temperature -20 °C to +80 °C
Storage temperature -30 °C to +90 °C
Ready for operation 2 h
Power supply 230V AC, (115V optional) 230V 50/60Hz oder 115V 50/60Hz switchable
Heating capacity 200W 0,6m: 600W, 1m: 800W, 1,5m: 1200W, 2m:
1200W
Electrical connections terminals, max. 2,5 mm
2
, 2x PG13,5 cable gland, terminal range 6-12mm
Electrical standard EN 61010, EN60519-1
Degree of protection IP54 EN 60529
Mounting flange DN65 PN6, Form B with 4 welded screws on both sides M 12x 40 mm
Material of parts in
contact with the sample stainless steel 1.4539, version SP30-H1.1/HC: Hastelloy C 1.4539,
1.4571/1.4401
