14.3
Technical specifications and illustrations are without
obligation, subject to modifications. 09.96/12.11
Gas Conditioning Unit series PSS ® version SS-5 version SS-5/3
Part No. for 230V 50Hz version 03G5000 03G5500
Part No. for 115V 60Hz version 03G5000a 03G5500a
Sample outlet dew point range of adjustment: +2 °C ..... +15 °C, factory setting: +5 °C
Dew point stability at constant conditions < ±0,1 °C
Sample inlet temperature** max. +80 °C optional: max. 180 °C with stainless steel bulkhead union
Sample inlet dew point** max. +80 °C
Gas flow rate** max. 150 Nl/hr max. 350 Nl/hr
Ambient temperature** +5 °C up to +40 °C
Storage temperature -25 °C up to +65 °C
Pressure 0,7 bar up to 1,4 bar abs.
Total cooling capacity at 25 °C ambient max. 50 kJ/hr max. 90 kJ/hr
Number of gas inlets 1
Number of gas outlets 1 optional: max. 4
Medium connections tube connection 4/6 mm
Material of sample contacting parts stainless steel, glass, PPH, PVC, PVDF, PTFE, Novoprene ®
Ready for operation approx. 10 min.
Power supply 230V 50Hz or 115V 60Hz
Power consumption max. 240VA
Fuse protection 4A t, 5x 20 mm, with option temperature controller: 10A t
Electrical connection terminals 4 mm
2
Case protection IP20 (DIN 40050. IEC 529)
Electrical equipment standard EN 61010
Mounting version aluminium mounting plate for wall mounting
Dimensions (WxHxD) 515 x 385 x 190 mm
Weight approx. 15,5 kg approx. 17,0 kg
** Maximum values in technical data’s must be rated in consideration of total cooling capacity at 25 °C ambient temperature and 5 °C outlet dew point.
PPH = Polypropylene
PTFE = Polytetrafluoroethylene (Teflon ® )
PVDF = Polyvinylidenfluoride
PVC = Polyvinylchloride
Novoprene®
Technical Data
Alternatively Part number
Flow meter FM40 mounted in sample gas outlet:
max. 4 pc. 7-70 l/hr air
15-150 l/hr air
25-250 l/hr air
50-500 l/hr air max. 4 pcs. 01G9070
01G9075
01G9080
01G9085
Temperature controller for heated sample line 230V 50Hz: range of control: 0 °C-200 °C, input PT100, 230V, max. 6A
max. length of the sample line 20 m 01G9055
Temperature controller for heated sample line 115V 60Hz: range of control: 0 °C-200 °C, input PT100, 115V, max. 6A
max. length of the sample line 10 m 01G9055a
Liquid alarm type LA 1/1.4 01G9035
5-way ball valve type 5L/PV-1 01G9045
Options
