Gas sampling and gas conditioning technology
2-1.0.1-ME
7 TECHNICAL
DATA
Gas Sample Probe Series SP®
SP210-H
SP210-H/W
Part No.
02S1000
02S1010
Weather protection shield
no
yes
Sample tube
Type SP210/SS, stainless steel 316Ti, length 1 m* optional*
Sample temperature
max. 600 °C*
Sample pressure
0.4 to 2 bar abs.
Ambient temperature
-20 °C to +60 °C
Recommended for dust loadings
up to 1 g/m
3
*
Filter chamber volume
100 ml
Filter element
S-2K, filter porosity 2 μm, ceramic
Probe heating temperature
+180 °C self-regulating
Ready for operation
after 2 hours
Temperature alarm contact, alarm
point
<160 °C, NO
Temperature alarm, contact rating
250V-3A AC, 30V-3A DC
Connection sample outlet
1/4"-NPT inside, with 6 mm tube connector
Power supply
110 up to 240V 50 / 60Hz
Power consumption
start up: 400VA, usual: 100VA, (fuse 6A)
Electrical connection
terminals max. 2,5 mm
2
, 2x PG11 cable gland
Electrical equipment standard
EN 61010, EN 60335-1
Degree of protection
IP54, EN 60529
IP55, EN 60529
Mounting flange
DN65 PN6,B stainless steel 316Ti
Material of sample contacting parts SS 316 / 316Ti, FPM, ceramic
Weight
6,5 kg
8,5 kg
Option
Part No.: 02 S 9200
Insitu probe tube out of stainless steel 316Ti type SP210/SS, connection
G3/4" o, ø 10/12, length 1 m*, incl. flange gasket.
* Standard, other versions on request.
ΔP und T90 at flow of:
100 200 500
Nl/h
ΔP pressure loss with new filter element S-2K:
0,007 0,011 0,020
bar
T90 time-without sample tube/prefilter-
6,0
3,5
1,0
Sec.
8 APPLICATIONS
The electrically heated M&C gas sample probes SP210-H and SP210-H/W gas sample probes are
used for continuous gas sampling in processes with dust densities of up to 1g/m³, operating pressure
up to max. 2 bar abs., temperatures of up to a maximum of 600°C or higher gas humidity. Thanks to
its compact design it requires only limited space. It has to be mounted in a weatherproof position. The
gas sample probe SP210-H/W is equipped with an extra protective cover preferably for outdoor
mounting.
