12

Gas sampling and gas conditioning technology

2-1.0.1-ME

N O T E !

Make sure that the connection is leakproof !

• Now place the red silicon heat insulation around the connection.



Mounting of sample tube and adapter flange:

• Screw either the probe tube directly into the ¾" inner thread in the flange of the probe with the

¾" flat gasket and tighten.

• If the heated probe tube type SP30/35 is used then the probe is to be screwed to their flange

(with welded threaded bolt). First insert the flange seal between the two flanges.

• If the probe connection does not correspond to the standard flange connection DN65 PN6,

then the optionally supplied adapter flange should be mounted to the probe in the same way.

• Attach the flange seal to the probe connection.

• Now insert the process-internal probe section of the complete probe unit into the probe

connection using the screws and nuts supplied.

N O T E !


A preferred mounting position is to have the probe with its sample gas outlet
pointing downwards, although this is not absolutely necessary for perfect
functioning.
