10
Gas sampling and gas conditioning technology 5-6.5.1-ME
13 DELIVERY
The flowmeter Series FM ® is normally delivered in one packaging unit:
The flowmeter Series FM ® should be removed carefully from the packaging and checked immediately
for completeness against the delivery note.
Check the goods for any damage incurred during transport and if necessary inform your transport
insurer of any damage.
14 PREPARATION AND INSTALLATION
Locate the flowmeter Series FM ® in such a way that there is adequate space for removing the cover
and replacing the glass tube. Fix the aluminium plate with 4 screws.
Make certain that the flowmeter Series FM
® is easily accessible so that you can carry out any
subsequent maintenance work without trouble.
15 MOUNTING

Loosen the two screws beside the window

Remove the cover of the flowmeter

Disconnect the thermal conductivity jaws on the bottom of the flowmeter in two parts by
loosening the screws, two each
N O T E !
Make sure that the connection is leak proof!

Connect the sample lines at the fittings

assemble the two thermal conductivity jaws on the bottom once again

Put the cover of the flowmeter on top and screw it
