8
Gas sampling and conditioning technology 5-5.3 ME
7 TECHNICAL DATA
Sensor KS2 KS2 Peek KS2.Ex
Part No. 03E4100 03E4110 03E4200
Pressure max. 2 bar abs. max. 11 bar abs. max. 2 bar abs.
Max. operating temperature 0°C to +60°C 0°C to +50°C
Liquid alarm limit 1,5ml
Material of sample
contacting parts PTFE, Chemraz,
SS316Ti Peek, Chemraz,
SS316Ti PTFE, Chemraz, SS316Ti
Sample connection Standard
(Fitting for mounting in
stainless steel filter:
connector GE SS ½“NPT-
18mm Part No.. 09V2317) ø16 mm for GL25 ø18 mm for
mounting in
stainless steel filter
FSS...-
D1/2“NPT
ø16 mm for GL25
Option sample connection
ø18 mm, Part No..: 03E9400
(Fitting for mounting in
stainless steel filter:
connector GE SS ½“NPT-
18mm Part No.. 09V2317) for mounting in
stainless steel filter
FSS...-
D1/2“NPT
for mounting in stainless
steel filter FSS...-
D1/2“NPT
Method of mounting /
mounting position clamping attachment / for liquid alarm vertical with opening
upwards
Max. voltage / current /
power consumption 13,5V / 31 mA / 125 mW
Inner capacity max. 150 nF
Inner inductivity max. 0 mH
Power supply 8-12VDC
feeding via FA1.4 or FA1.1 8V DC / max.2,4mA
operating: < 1,4 mA alarm
Connection cable, length 1,5
m standard 3 x 0,25mm² 2 x 0,25mm²
Cable
capacity
inductivity
200pF/m
1µH/m
Protection IP 54 DIN 40050
II 1 G EEx ia IIC T6
KEMA 03ATEX1006
Weight 190 g
