2.12
Technical specifications and illustrations are without
obligation, subject to modifications. 10.04/11.12
Options Version Part No.
Stainless steel pre-filter with volume displacer, length 220mm, 46mm o.d., filter porosity 2µm,temperature max. 600°C, material
SS316 V20-0 20 S 9105
Hastelloy pre-filter with volume displacer, length 220mm, 46mm o.d., filter porosity 2µm, temperature max. 900°C, material
Hastelloy-C V20-0/HC 20 S 9115
Stainless steel pre-filter with volume displacer, length 520mm, 60mm o.d., filter porosity 2µm, temperature max. 600°C, material
SS316 V20-1 20 S 9145
Hastelloy pre-filter with volume displacer, length 520mm, 60mm o.d., filter porosity 2µm, temperature max. 900°C, material
Hastelloy-C V20-1/HC 20 S 9155
Hastelloy pre-filter with volume displacer, length 520mm, 60mm o.d., filter porosity 0,5µm,temperature max. 900°C, material
Hastelloy-C V20-1/HC 20 S 9156
Stainless steel pre-filter with volume displacer, length 300mm, 31mm o.d., filter porosity 2µm, temperature max. 600°C, material
SS316 V20-3 20 S 9300
Extra charge for extension of insitu stainless steel filter V20-3 or V20-4 for each 100 mm further length (from standard length
300mm to .... mm), max. 1000 mm total filter length, material: SS316.········· V20-3 20 S 9310
Backflushable hose pre-filter with internal support tube, length: 400mm, 40mm o.D., filter porosity 15µm,temperature max.
200°C, material PTFE, SS316 V20-T 20 S 9315
Insitu ceramic filter tube in double-layer version for high blow back efficiency, with volume displacer, length 500mm, 40mm
o.d., filter porosity 1µm, temperature max. 1000°C, material ceramic, SS316, connection G3/4" V12-1A-1 20 S 9559
Extension tube for V20.. with internal volume displacer , length 500mm, temperature max. 600°C, material SS316 Vm500 20 S 9165
Extension tube for V20.. with internal volume displacer , length 1000mm, temperature max. 600°C, material SS316 Vm1000 20 S 9170
Extension tube for V20.. with internal volume displacer , length 1500mm, temperature max. 600°C, material SS316 Vm1500 20 S 9175
Options sample tubes
Options Version Part-No.
Length 1m, material SS316Ti, temperature max. 600 °C SP2000/SS 20 S 9065
Length 1m, with volume displacer, material SS316Ti, Temperatur max. 600 °C SP2000/SS-Vm 20 S 9067
Length 1m, material Hastelloy-C, temperature max. 900 °C SP2000/HC 20 S 9090
Length 1m, material Kanthal, temperature max. 1300 °C SP2000/KA 20 S 9080
Length 1m, material Incoloy 956, temperature max. 1200 °C SP2000/IC 20 S 9072
For choosing the adequate pre-filter see data sheet 2-1.1.0.8 as well
For choosing the adequate sample tube see data sheet 2-1.1.0.6 as well
Options pre-filter and extension tubes
Part number T-Class ATEX Cenelec/IEC/NEC 505 T-Class FM/CSA NEC 500 Operating temperature °C Limiter °C
20S9608 T2 T2 230 235
20S9609 T2A 215 220
20S9610 T3 T2B 185 190
20S9611 T2C 175 180
20S9612 T2D 160 165
20S9613 T3 150 155
20S9614 T3A 135 140
20S9615 T4 T3C 120 125
20S9616 T4 95 100
20S9617 T5 T4A 85 90
20S9618 T5 70 75
Temperature classes (Please indicate desired temperature class with your order)
The programming and closing of the controller is effected at works in compliance with the indications in your order.
