2.12
Technical Data
* Standard, ** Option
Technical specifications and illustrations are without
obligation, subject to modifications. 10.04/11.12
Gas sample probe type SP3200V (up to 185 °C) SP3200 (more than 185 °C)
Optionƒvariableƒcalibrationƒgasƒfeeding /Rƒ+ƒ/CCƒandƒ/CCF
Part No. 20S9045 + 20S9012
Way of test gas /R/CC = via sample gas outlet or /R/CCF = via probe filter element
Check valve /R check valve 1/4”
Opening pressure >0,7 bar
Connection 6mm tube
Maximum blow back pressure 6 bar abs.
Maximum operating temperature +185 °C
Option high performance blow back valve /BB /BBF
Part No. 20S9008 20S9006
Way of blow back gas via filter chamber via probe filter element
Check valve high performance check valve 3/8”
Opening pressure >0,7 bar
Connection 8mm tube
Maximum blow back pressure 6 bar abs.
Maximum operating temperature 185 °C
Option test gas valve / shut-off valve /C + /I
Part No. 20S9011 + 20S9009
Way of test gas via sample gas outlet with shut-off to the process
Check valve check valve 1/4”
Opening pessure >0,7 bar
Connection 6mm tube
Shut-off valve bellow-type valve with pneumatic drive
Pressure control air 3-10 bar
Connection control air 1/8” NPT i
Option second sample gas outlet /2X
Part No. 20S9015
Connection 1/4” NPT i
Optionƒspunƒglassƒcartridge /FW
Part No. 20S9047 20S9046
Material SS316Ti, Novapress SS316Ti, Graphite
∆P and T90 at flow of: 100 200 500 1000 1500 Nl/hr
∆P with new filter element F-3SS150 0,006 0,012 0,040 0,110 0,215 bar
∆P with new filter element S-2K150 0,003 0,005 0,02 0,058 0,135 bar
T90-time for SP3200 without tube 6 3,5 1 <0,5 <0,5 s
Differential pressure and T
90
-time
X = possible combinations
X = recommended combinations
Combinations of options
Option No. 1 2 3 4 5 6 7a 7b 8 9 10
/RS /VA /3VA /MS1 /R /R/CC(/CCF) /BB /BBF /C/I /2X /FW
/RS X X X
/VA X X X X X X X X
/3VA X X X
/MS1 X X
/R X
/R/CC(CCF) X X X
/BB X X X X
/BBF X X X
/C/I X X X X X X
/2X X X X X X X
