Technical Data

Technical specifications and illustrations are without

obligation, subject to modifications. 10.04/11.12

Gas sample probe type

SP3200V (up to 185 °C)

SP3200 (more than 185 °C)

Part No.

20S5705

20S5700

Weather protection shield

yes

Filter housing material

Stainless steel 316 / 316Ti

Sealing materials

Graphite, FPM

Graphite

Probe flange sealing material

Graphite

Pre-filter / sample tubes

optional, see data sheet 2-1.1.0.6 and 2-1.1.0.8

Sample pressure max.

0,5-6 bar

Ambient temperature

-20 °C to +60 °C

Permissible process gas temperature

depending on the temperature class, however max. 200°C at the probe entry

Filter chamber volume

120 cm

Filter element, porosity

F-3SS150= stainless steel*, 3 micron S-2K150= ceramic**, 2 micron

Sample gas outlet connection

1x 1/4“ NPTi for max. 8mm-tube connectors

Connection gas outlet at option RS

6 mm Swagelok connector

Mounting flange

DN65 PN6, FormB, SS316Ti* >DN or ANSI possible**

Weight

7 kg

Option heating type HEX5

HEX5-1.08

HEX5-2.08

Part No.

20S9650 (a)

20S9655 (a)

Mounting controller

in the Ex-zone 2 and 22

Control

electronic

Power supply

240V 50/60Hz or 120V 50/60Hz (a)

Electrical connection

cable gland, terminal range 6-12mm, terminals max. 4mm

Marking

II 3 G Ex nA nC nL IIC T5 to T2,

II 3 D Ex tD A22 IP65 T75°C to T235°C

Class I, Division 2, Groups A/B/C/D, T5 - T2B

Power

max. 800 W (240V), max. 830 W (120V)

Case protection

IP65; EN60529

Operating temperature

0 - max. 230 °C

Ambient temperature

0 °C to +50 °C

controller: 0 °C bis +50 °C, heater: -20 °C bis +70 °C

Low temperature alarm contact

-5 °C to Tset make contact potential free with breaking capacity 250V 3A AC, 0,25A DC

Option back purge unit type RS

Part No.

20S5560 (a)

Power supply

230V 50/60Hz 9W or 115V 50/60Hz 9W (a)

Electrical connection

cable 3x1mm

Marking

II 3GD T4

Connection

G 1/2”i at the buffer vessel

Max. back purge pressure

6 bar abs.

Volume buffer vessel

2 liters

Ambient temperature

-20°C to 60°C

Option 2-way-ball valve in the probe entrance

/VA

Part No.

20S9050

Operating temperature

-20°C up to 185°C

Option 2/3-way-ball valve in the probe entrance

/3VA

Part No.

20S9325

Backflush / Test gas connection

6mm tube

Operating temperature

-20°C up to +185°C

Option pneum. drive for ball valve /VA o. /3VA

MS1

Part No.

20S9055

Connection control air

G1/4” i

Pressure control air

5-10 bar

Option valve for blowback or calibration gas 1/4”

Part No.

20S9045

Opening pressure

>0,7 bar

Connection

6mm tube

Maximum blow back pressure

6 bar abs.

Maximum operating temperature

+185 °C
