IPDirector Version 5.9 – User Manual – Part 1: General Workspace
EVS Broadcast Equipment -– January 2011
Issue 5.9.B
83
• press + .
3.
The channels are now shown with the PGM and PRV icons:
Note
You can only make a PGM/PRV pair of PGM1-PGM2 or PGM3-PGM4 on
any EVS server. PGM1 or PGM3 are always the PGM channels and PGM2
or PGM4 will always be the PRV channels.
3.3.11 H
OW TO
A
SSOCIATE
C
HANNELS IN
F
ILL
& K
EY
M
ODE
Channels of the EVS servers can be ganged in a specific style called Fill & Key.
This mode manages assignments of clips or playlists, and forces them to recall to
the appropriate channels, so as to allow you to perform synchronized clip or
playlist recalls in a Fill & Key scenario (sometimes called Matte & Fill).
To associate channels in Fill & Key mode, proceed as follows:
1. Select two channels with SHIFT+click or CTRL+click.
2.
• Right-click one of the selected channels and select Fill Key.
OR
