IPDirector Version 5.9 – User Manual – Part 1: General Workspace
EVS Broadcast Equipment -– January 2011
Issue 5.9.B
49
4. Enter a name for the new toolbar and click OK.
The new layout toolbar name is displayed in the Layout Toolbar field.
H
OW TO
A
DD A
L
AYOUT TO A
L
AYOUT
T
OOLBAR
To add a layout to a Layout toolbar, proceed as follows:
1. Click the Layout tab on the left screen border to open the Layout panel.
2. Right-click the grey empty region under the blue Layout Toolbar field.
The following contextual menu is displayed:
3. Select New from the menu.
The Link Layout window opens and displays the list of existing layouts:
4. Select a layout and click Link.
Refer to section ‘How to Create a New Layout’ on page 43.
5. If required, repeat steps 1 to 3 to add more layouts to the toolbar.
The icons corresponding to the selected layout are displayed in the Layout Panel.
