Issue 5.9.B IPDirector Version 5.9 – User Manual – Part 1: General Workspace
EVS Broadcast Equipment – January 2011
98
From this window, you will be able to
• assign channels to the remote Function buttons
• select a remote layout
• define target destinations to send the controlled media to
• monitor the connection status.
Assigning Channels to Function Buttons
Refer to section ‘How to Assign Player or Recorder Channels to Function Buttons
in Favorite Mode’ on page 106.
Using a Remote Layout
Only clips and playlists can be controlled by the device and only one layout is
available from the Choose a Layout field.
Clicking on the View button opens the Layout Form window which shows the name
of the functions assigned to each button. No action can be performed from this
window.
