Issue 5.9.B IPDirector Version 5.9 – User Manual – Part 1: General Workspace
EVS Broadcast Equipment – January 2011
104
Button Description
Browse options) inserts the loaded clip to the default
playlist, before or after the loaded element, depending
on the setting.
• SHIFT - MENU button: switches the function buttons
assignment between the normal mode (all channels of
an EVS video server) and the favorite mode (channels
defined in the Remote Control Manager window).
The MENU LED flashes red in favorite mode.
• SHIFT - VAR button and SHIFT - JOG button: refer to
section ‘Wheel Mode Buttons’ on page 104.
• SHIFT – F1 button: used to associate the Software
Player to the remote.
CLEAR The CLEAR button is used prior to another button to
modify the behavior of this button. When it is activated,
its LED is red.
• CLEAR - IN: works as CLEAR IN
• CLEAR - OUT: works as CLEAR OUT
• CLEAR - ENTER: cancels the applied saved filter in the
Database Explorer.
ENTER The ENTER button can be used alone (see below) or
together with other buttons (refer to the description of the
other buttons)
• In Browse mode, in the Last Created Clips list and in
the Search on TC list, when a clip is loaded on the
controlled channel, pressing the ENTER button
appends it to the default playlist.
• In the SEL XT and the SEL REC lists: pressing the
ENTER button confirms the selection.
• In the Database Explorer tree view: opens or closes a
tree node.
• In the saved filter pane of the Database Explorer:
applies the selected saved filter.
Wheel Mode Buttons
Three buttons are available to select the mode according to which the wheel will
be used. As some of these buttons can be used in association with other buttons,
a totality of 5 wheel modes are available to the users.
Pressing a Mode button activates a wheel mode but does not change the playout
speed.
VAR Mode
The Var wheel mode enables to move in the loaded media at a selected constant
review speed. It is activated by pressing the VAR button. The LED is red.
