Issue 5.9.B IPDirector Version 5.9 – User Manual – Part 1: General Workspace
EVS Broadcast Equipment – January 2011
6
Features of the Database Explorer window include:
• bin management
• log sheet management
• timecode or free text search engine and search filters
• keyword filter and assignment
• thumbnail displays
• metadata details (ID, name, timecode, keywords, UmID…)
• fill & key management of clips and playlists
• browse and playback directly from explorer window
• export of log sheets (XML, CSV)
• archive management via XFile
1.1.4 R
ECORDER
P
ANEL
The Record Panel is the graphical user interface used to control the recorder
channels of an EVS server. The Recorder Control Panel shows the record status
of a channel and can enable channels to start or stop recording depending upon
the EVS server base configuration. In conjunction with the buttons on the VGA,
there are also keyboard shortcuts and dedicated buttons on the optional
ShuttlePRO controller. Where they are shown, these are the default settings.
Note
If the EVS server is operating in the LSM mode, the Recorder Panel will
not be able to stop the recorders. This is due to superiority of the LSM
remote in the configuration.
1.1.5 I
NGEST
S
CHEDULER
Ingest Scheduler allows for clips and streams to be automatically created from any
record channel under the control of IPDirector at either a time scheduled in
