IPDirector Version 5.9 – User Manual – Part 1: General Workspace
EVS Broadcast Equipment -– January 2011
Issue 5.9.B
99
Selecting Destination Targets
From the Destinations area of the Remote Control Manager window, you select the
destination targets where the media will be sent to when using the Send to button.
The available targets and nearline are the same as those available from the Save
Clip window. Refer to part 5 of the user manual.
BEP
LAY
R
EMOTE
B
UTTONS
The BEPlay remote device has different kinds of buttons, each of them is
described in the following sections:
• Function buttons, labeled F1 to F6,
• Action buttons,
• Special buttons: MENU, SHIFT, CLEAR, ENTER,
• Wheel Mode buttons: VAR, SHUTTLE, JOG.
Function Buttons
Function buttons are used to control a recorder or a player channel, or the
Software Player. The LED of a function button gives the following indication:
The LED of a
Function button… …when
is green a player channel or the Software Player is assigned to the
button
flashes green the player channel or the Software Player assigned to the
button is being controlled by the Remote
is red a recorder channel is assigned to the button
flashes red the recorder channel assigned to the button is loaded on
the channel controlled by the Remote
is not turned on
• no channel is assigned to the button, or
• the user cannot see the recorder channel or control the
player channel, or
• the Software Player is not opened.
Action Buttons
The BEPlay Remote provides 14 buttons which can all be used to perform two
different actions, depending on whether the SHIFT button is pressed prior to the
button.
When you use the ‘Clips/Playlists’ layout, the action may differ according to the
media type (clip, playlist, train or playlist element) loaded on the channel
controlled by the remote.
