190-01146-00 Rev. A Garmin G950 Pilot’s Guide for the Tecnam P2006T 53
FLIGHT INSTRUMENTS
SY
STEM
O
VER
VIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO P
ANEL
& CNS
FLIGHT
MANA
GEMENT
HAZARD
AV
OID
ANCE
AFCS
ADDITIONAL
FEA
TURES
APPENDICES
INDEX
A Baro Transition Alert is provided to notify the pilot to change the barometric pressure setting when crossing
the baro transition altitude. If the aircraft is at least 500 feet below the transition altitude and then climbs
through this altitude and the STD BARO Softkey has not been pressed, the barometric pressure setting flashes
in light blue until the pressure setting is changed. If the aircraft is at least 500 feet above the transition altitude
and then descends through this altitude and the barometric pressure setting has not been changed from STD
BARO, the setting flashes in light blue until it is changed (Figure 2-12).
Setting the Baro Transition Alert:
1) Use the FMS Knob to select the AUX - System Setup Page.
2) Press the FMS Knob to activate the cursor.
3) Turn the large FMS Knob to highlight ‘OFF or ON’ in the ‘BARO TRANSITION ALERT’ box.
4) Turn the small FMS Knob to turn the alert OFF or ON and press the ENT Key.
5) With the altitude field highlighted, turn the small FMS Knob to select the desired altitude and press the ENT
Key.
6) To cancel the selection, press the FMS Knob.
Figure 2-12 Baro Transition Alert
(AUX - System Setup Page)
Pressure setting flashes during climb above
transition altitude if the STD BARO Softkey
has not been pressed.
Pressure setting flashes during descent below
transition altitude to indicate setting has not
been changed from STD BARO.
