MCS
Multi-display
< 2.3 > Get Name
•
Function
The computer shows the name of the LCD display
• Get LCD Display Address
Header
Command
ID
Val 1
Val 2
Val 3
Val 4
Val 5
Val 6
0x06, 0 x4D,0x43
0x03
0x00
0x00
0x00
0x00
0x00
0x00
•
Ack
Header
Command
ID
Val 1
Val 2
Val 3
Val 4
Val 5
Val 6
0x4D, 0x4 3,0x06
0x0 3
Char1
Char 2
Char3
Char4
Char5
Char6
Char1 :
The 1st character of the name
Char2 :
The 2nd character of the name
Char3 :
The 3rd character of the name
Char4 :
The 4th character of the name
Char5 :
The 5th character of the name
Char6 :
The 6th character of the name
*The default value of the character of the nam e is 0xFF
•
Nak
He ader
Co mmand
ID
Val 1
Val 2
Va l 3
Val 4
Val 5
Val 6
0x4D, 0x43 ,0x15
0x03
ERR
0x0 0
0x00
0x00
0x00
0x00
