< 2.16 > Sound Select Control
• Function
The computer switches the sound setting of the LCD display
The PIP function may or not be available on a particular LCD dis play depending on
• Set Sound
Header
Command
ID
Val 1
Val 2
Val 3
Val 4
Val 5
Val 6
0x0 6, 0x4D,0x43
0x2 5
S.S el
0x00
0 x00
0x00
0x00
0x00
S.Sel :
The sound s elec t code for the LCD display
0x01
Main
0x02
P IP
•
Ack
He ader
Co mmand
ID
Val 1
Val 2
Va l 3
Val 4
Val 5
Val 6
0x4D, 0x43 ,0x06
0x25
S.Sel
0x0 0
0x00
0x00
0x00
0x00
•
Nak
He ader
Co mmand
ID
Val 1
Val 2
Va l 3
Val 4
Val 5
Val 6
0x4D, 0x43 ,0x15
0x25
ERR
0x0 0
0x00
0x00
0x00
0x00
