< 2.9 > Set Display Name
• Function
The computer sets the name of the LCD display.
• Set Display Name
Head er Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x16 Char1 Char2 Char3 Char 4 Char 5 Char6 0x0D, 0x0 A
Char1 : The 1st character of the name
Char2 : The 2nd character of the name
Char3 : The 3rd character of the name
Char4 : The 4th character of the name
Char5 : The 5th character of the name
Char6 : The 6th character of the name
*Character of the nam e c an allow [ a~z ],[ A~Z] , [ 0-9 ] & space character.
• Ack
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Che cksum
Footer
0x4D, 0x43,0x06 0x16 Char 1 Char2 Char3 Char4 Char5 Char 6 0x0D, 0 x0A
• Nak
Heade r Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Foo ter
0x4D, 0x43,0x15 0x16 ERR 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
