< 2.20 > Power Control
• Function
The computer switches the power for the screen of LCD display
• Set Power
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Va l 6
Checksum
Footer
0x0 6, 0x4D,0x43 0x45 Power 0x00 0x00 0x00 0x00 0x00 0x0D, 0 x0A
Power : The power code for the s creen of LCD display
0x00 Power OFF
0x01 Power ON
• Ack
He ader Co mmand
ID
Val 1 Val 2 Va l 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43 ,0x06 0x45 Power 0x0 0 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Nak
He ader Co mmand
ID
Val 1 Val 2 Va l 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43 ,0x15 0x45 ERR 0x0 0 0x00 0x00 0x00 0x00 0x0D, 0x0A
