< 2.6 > Get Screen Status
• Function
The computer shows the current screen setting of the LCD display
• Get Sc reen Status
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Che cksum
Footer
0x06, 0x4D,0x43 0x0 6 0x00 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Ack
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Foo ter
0x4 D, 0 x43,0x06 0x06 Ctrast Br ight 0x00 0x00 0x00 0x00 0x0D, 0x0A
Ctrast : The contrast value of the display
Bright : The brightness value of the display
• Nak
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x0 6 ERR 0x00 0x00 0 x00 0x00 0x00 0x0D, 0 x0A
