< 2.18 > Brightness Control
• Function
The computer adjusts the brightness of the LCD display
• Set Brightness
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x27 Bright 0x00 0 x00 0x00 0x0 0 0x00 0x0D, 0x0A
Bright : The brightness value code for the LCD dis play ( 0~ 100 )
• Ack
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x06 0x27 Bright 0x00 0x00 0x00 0x00 0 x00 0x0D, 0 x0A
• Nak
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x27 ERR 0x00 0x00 0x00 0x00 0 x00 0x0D, 0 x0A
