Acnodes MCS - Manual (Page 19)

< 2.13 > Input Source Select
• Function
The computer changes the input source of the LCD display
Some of inputs may or not be available on a particular LCD display depending on the model selected
• Set Input Source
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x22 Input 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
Input : The input source code for the LCD display
0x10 V GA
0x11 S-Vide o
0x12 Composite
0x13 DVI-D
0x14 HDMI
0x15 S DI
0x16 YPbPr
0x17 TV
• Ack
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x06 0x22 Input 0x00 0x00 0x00 0x00 0 x00 0x0D, 0 x0A
• Nak
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x22 ERR 0x00 0x00 0x00 0x00 0 x00 0x0D, 0 x0A
