< 2.5 > Get Display Status
•
Function
The computer shows the current s etting of the LCD display
•
Get LCD Display Address
Header
Command
ID
Val 1
Val 2
Val 3
Val 4
Val 5
Val 6
0x06, 0 x4D,0x43
0x05
0x00
0x00
0x00
0x00
0x00
0x00
•
Ack
Header
Command
ID
Val 1
Val 2
Val 3
Val 4
Val 5
Val 6
sum
0x4D, 0x4 3,0x06
0x0 5
Vol
Mute
Input
OSDB
IR
Sound
Vol :
The volume value of the LCD display ( 1~100 )
Mute :
The mute code for the LCD display
Input :
The input source code for the LCD display
OSDB :
The OSD button control code for the LCD display
IR :
The infrared remote control code for the LCD display
Sound :
The sound select code for the LCD display
•
Nak
He ader
Co mmand
ID
Val 1
Val 2
Va l 3
Val 4
Val 5
Val 6
0x4D, 0x43 ,0x15
0x05
ERR
0x0 0
0x00
0x00
0x00
0x00
