< 2.19 > Auto Adjust Control
• Function
Auto adjusts the VGA picture position on the screen
Available only when input sour ce is VGA
• Set Auto A dust
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0 x4D,0x43 0x28 A.Adj 0x00 0x00 0x00 0x00 0x00 0x0D, 0 x0A
A.Adj : The auto adjust code for the LCD display ( 0x00 )
• Ack
Header Comm and
ID
Val 1 Val 2 Va l 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x4 3,0x06 0x28 A.Adj 0x0 0 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Nak
Header Comm and
ID
Val 1 Val 2 Va l 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x4 3,0x15 0x28 ERR 0x0 0 0x00 0x00 0x00 0x00 0x0D, 0x0A
