< 2.10 > Show Display ID & Name
• Function
The LCD Display shows the ID number & name on the screen
• Show Display ID and Name
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Va l 6
Checksum
Footer
0x06, 0x4D,0x43 0x17 Time 0x 00 0x00 0x00 0x00 0x00 0x0D, 0x0A
Tim e : The second value for the s creen shows the display ID no. & name ( 5~255 )
• Ack
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Foo ter
0x4D, 0x43,0x06 0x17 Time 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Nak
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x17 ERR 0x00 0x00 0x00 0x00 0 x00 0x0D, 0 x0A
