< 2.2 > Get Address
• Function
The com puter shows the 32-bit MAC addres s of the LCD display
• Get LCD Display Address
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x02 0x00 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
• Ack
Header Comm and
ID
Val 1 Va l 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x06 0x02 MAC1 MAC2 MAC3 MAC4 0x00 0x00 0x0D, 0x0A
• Nak
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x02 ERR 0x00 0x00 0x00 0x00 0 x00 0x0D, 0 x0A
