< 2.8 > Set Display ID
• Function
The computer changes the LCD display ID num ber.
• Set Dis play ID number
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Va l 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x1 5 NewID 0x00 0 x00 0x00 0x00 0x00 0x0D, 0x0A
NewID : Changes the LCD dis play ’s ID to New ID number (1~64).
*The new ID number will be treated as bad parameter, if the num ber is 0, 65 ~ 255 or the
new ID number already occupied by other LCD display.
• Ack
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Foo ter
0x4 D, 0 x43,0x06 0x15 NewID 0x00 0 x00 0x00 0x00 0x00 0x0D, 0x0A
• Nak
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x1 5 ERR 0x00 0x00 0 x00 0x00 0x00 0x0D, 0 x0A
