< 2.12 > Mute Control
• Function
The computer turns the mute ON or OFF of the LCD display
The audio function may or not be available on a particular LCD display depending on the model selected
• Set Mute Control
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x06, 0x4D,0x43 0x21 Mute 0x00 0x00 0x00 0x00 0x00 0x0D, 0x0A
Mute : The mute code for the LCD display
0x00 Mute OFF
0x01 Mute ON
• Ack
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x06 0x21 Mute 0x00 0x00 0x00 0x00 0 x00 0x0D, 0 x0A
• Nak
Header Command
ID
Val 1 Val 2 Val 3 Val 4 Val 5 Val 6
Checksum
Footer
0x4D, 0x43,0x15 0x21 ERR 0x00 0x00 0x00 0x00 0 x00 0x0D, 0 x0A
