< 2.24 > PIP Location Control
• Function
The computer adjusts the PIP position of the display
The PIP function may or not be available on a particular LCD display depending
Available only when the PIP is in sm all or large size state
• Set PIP location
Head er
Command
ID
Val 1
Val 2
Val 3
Val 4
Val 5
Val 6
0x06, 0x4D,0x43
0x53
P.Loc
0x00
0x00
0x00
0x00
0x00
P.Loc :
The PIP location code for the LCD display
0x10
Upper Left
0x11
Upper Right
0x12
Lower Left
0x13
Lower Right
• Ack
Header
Command
ID
Val 1
Val 2
Val 3
Val 4
Val 5
Val 6
0x4D, 0x43,0x06
0x53
P.Loc
0x00
0x00
0x00
0x00
0 x00
• Nak
Header
Command
ID
Val 1
Val 2
Val 3
Val 4
Val 5
Val 6
0x4D, 0x43,0x15
0x53
ERR
0x00
0x00
0x00
0x00
0 x00
