< 2.22 > PIP Source Control
**The PIP is operable in the following table:
PIP
Main
VGA
S-Video
Comp os-
ite
DVI-D
HDMI
SDI
VGA
X
O
O
O
O
O
S-Video
O
X
X
O
O
O
Composite
O
X
X
O
O
O
DVI-D
O
O
O
X
X
O
HDMI
O
O
O
X
X
O
SDI
O
O
O
O
O
X
YPbPr
O
O
O
O
O
X
TV
O
X
X
O
O
O
