Page 43: Hub specifications a-1
A
S
PECIFICATIONS
This appendix lists the specifications for the LinkBuilder FMS 100-TX Hub.
Hub Specifications
Physical Dimensions
Length:
30.48 cm (12 in.)
Width:
43.94 cm (17.3 in.)
Height:
4.37 cm (1.72 in.)
Weight:
5.5 kg (12 lb)
Environmental Operating Ranges
Operating temperature:
0˚ to 40˚ C (34˚ to 104˚ F)
Storage temperature:
–30˚ to 60˚ C (–22˚ to 140˚ F)
Humidity:
10% to 90% relative humidity, noncondensing
Altitude:
3,050 m (10,000 ft) operating
Power Requirements
AC input voltage:
100–240 VAC, 47–63 Hz
Inrush current:
20 A peak for 1/2 cycle @ 250 VAC
AC input isolation:
2000 VAC
Power consumption:
40 W maximum
Heat output:
136.5 BTU/hr
User-replaceable fuse:
Fast-blow 2 A, 250 V
Repeater Classification
Class I
