2

I

NSTALLING

THE

FMS 100-TX H

UB

This chapter discusses the following topics:

Unpacking the hub

Positioning the hub

Installing the hub

Installing the transceiver interface modules

Using the Redundant Power System

Replacing the fuse

Unpacking the
Hub

When unpacking the hub, follow these steps:

1 Open the shipping container and carefully remove its contents.

2 Return all packing materials to the shipping container and save it.

If the hub must be returned, ship it in its original shipping container (or one
providing equivalent protection), or the warranty will be voided.

3 Verify that you have received all items that are shipped with the hub, as

listed below.

4 Inspect each item for damage. If you find any omissions or damage, contact

your network supplier and the carrier that delivered the package.

Each LinkBuilder FMS 100-TX hub is shipped with the following:

Rack mounting kit containing two brackets and four screws

Four rubber feet for desktop placement

AC power cord
