Specifying print format parameters
4-60 Using LCDS Print Description Language
Default Top left corner of the portrait or landscape oriented page, scaled
at 1/1
OUTPUT IMAGE
parameter: points
to note
• To put an image on a page, use a form with the image, or use
the IMAGE DJDE.
• If the UN option is used to define positioning, the UNITS
parameter must precede this command.
• The IMAGE parameter must follow the GRAPHICS=BATCH
parameter, as these two parameters are order dependent.
• If two IMAGE parameters are listed consecutively in a JDL,
the system processes only the second one.
• Existing .IMG files are printed in the system default black ink
unless ink references are specified in the INK parameter.
• If ink references are used:
– If one inkref in the list is omitted, commas must be used
as place holders to maintain the relative positioning of the
remaining ink references.
– If more than two ink references are specified, the
additional ink references are ignored.
OUTPUT IMAGE
parameter
example
Following is an example of the OUTPUT GRAPHIC parameter.
OUTPUT INVERT
Specifies that the content of a page will be inverted 180 degrees
when it is printed on the physical page, head to head or head to
toe. Inversion is also used for page orientation for finishing
functions.
Syntax OUTPUT INVERT = {FRONT | BACK | BOTH | NONE}
Options
OUTPUT GRAPHIC=BATCH, IMAGE=(1 IN,2 CM);
Table 4-60. OUTPUT INVERT parameter options and
definitions
Option Definition
FRONT Specifies page inversion on front sides.
BACK Specifies page inversion on back sides.
