P312 Broadband Security Gateway
9-2 System Information & Diagnosis
9.1 System Status
The first selection, System Status, gives you information on the version of your system firmware and the
status and statistics of the ports, as shown in the figure below. System Status is a tool that can be used to
monitor your Prestige. Specifically, it gives you information on your system firmware version, number of
packets sent and number of packets received.
To get to the System Status:
Step 1.
Enter number 24 to go to Menu 24 - System Maintenance.
Step 2. In this menu, enter number 1 to open System Maintenance - Status.
Step 3. There are three commands in Menu 24.1 - System Maintenance - Status. Entering 1 drops the
WAN connection, 9 resets the counters and [Esc] takes you back to the previous screen.
The table below describes the fields present in Menu 24.1 - System Maintenance - Status. It should be
noted that these fields are READ-ONLY and are meant to be used for diagnostic purposes. The upper right
corner of the screen shows the time and date according to the format you set in Menu 24.10 (Figure 11-6).
Figure 9-2 Menu 24.1 - System Maintenance – Status
Menu 24.1 - System Maintenance - Status 23:10:28
Sat. Jan. 01, 2000
Port
WAN
LAN
Status
10M/Half
10M/Half TxPkts
67
299
RxPkts
289
220
Cols
0
0
Tx B/s
74
74
Rx B/s
64
64
Up Time
2:20:56
2:20:54
Port:
WAN
LAN
Ethernet Address
00:a0:c5:21:8c:a3
00:a0:c5:21:8c:a2 IP Address
x.y.155.97
192.168.1.1 IP Mask
255.255.255.0
255.255.255.0
DHCP
Client
Server
System up Time: 22:11:43
Name: xxx.baboo.mickey.com
Routing: IP
ZyNOS F/W Version: V_0712_ | 7/12/2000
Press Command:
COMMANDS: 1-Drop WAN 9-Reset Counters ESC-Exit
