P312 Broadband Security Gateway

Filters

7-9

Field

Description

Option

don’t-care if it is 0.

Destination: Port #
Comp

Select the comparison to apply to the destination port in
the packet against the value given in Destination: Port #.

None/Less/Greater/

Equal/Not Equal]

Source: IP Address

Enter the source IP Address of the packet you wish to
filter. This field is a don’t-care if it is 0.0.0.0.

IP Address

Source: IP Mask

Enter the IP mask to apply to the Source: IP Addr.

IP Mask

Source: Port #

Enter the source port of the packets that you wish to filter.
The range of this field is 0 to 65535. This field is a don’t-
care if it is 0.

0-65535

Source: Port #
Comp

Select the comparison to apply to the source port in the
packet against the value given in Source: Port #.

None/Less/Greater/

Equal/Not Equal

TCP Estab

This field is applicable only when IP Protocol field is 6,
TCP. If yes, the rule matches only established TCP
connections; else the rule matches all TCP packets.

Yes/No

More

If yes, a matching packet is passed to the next filter rule
before an action is taken; else the packet is disposed of
according to the action fields.

If More is Yes, then Action Matched and Action Not
Matched will be N/A.

Yes / No

Log

Select the logging option from the following:

!

None – No packets will be logged.

!

Action Matched - Only packets that match the rule
parameters will be logged.

!

Action Not Matched - Only packets that do not
match the rule parameters will be logged.

!

Both – All packets will be logged.

None

Action Matched

Action Not Matched

Both

Action Matched

Select the action for a matching packet.

Check Next Rule

Forward

Drop

Action Not Matched

Select the action for a packet not matching the rule.

Check Next Rule

Forward

Drop
