Prestige 128IMH ISDN Modem/ Router/Hub
Hardware Installation and Setup 2-19
Figure 2-11 Loopback test
2.9 Ethernet Setup
This section describes how to configure the Ethernet using Menu 3 – Ethernet Setup. From the
Main Menu, enter 3 to open Menu 3.
Figure 2-12 Menu 3 - Ethernet Setup
2.9.1 General Ethernet Setup
This menu allows you to specify the filter sets that you wish to apply to the Ethernet traffic. You
seldom need to filter Ethernet traffic, however, the filter sets may be useful to block certain
packets, reduce traffic and prevent security breaches.
Menu 3 - Ethernet Setup
1. General Setup
2. TCP/IP and DHCP Setup
3. Novell IPX Setup
4. Bridge Setup
Enter Menu Selection Number:
Menu 3.1 - General Ethernet Setup
Input Filter Sets:
protocol filters= 2
device filters=
Output Filter Sets:
protocol filters=
device filters=
Press ENTER to Confirm or ESC to Cancel:
