14-4 System Maintenance
WAN
CHAN 1 IP Addr Refers to the IP address of the Prestige on Channel 1.
CHAN 2 IP Addr Refers to the IP address of the Prestige on Channel 2.
Port 1 CLID Shows the Caller ID of the peer on Port 1.
Port 2 CLID Shows the Caller ID of the peer on Port 2.
LAN Packet Which
Triggered Last Call Shows the first 48 octets of the LAN packet that triggered the
last outgoing call.
Figure 14-3 LAN Packet That Triggered Last Call
The figure above shows two examples of triggering packets from the LAN: the first of an ICMP
ping packet (Type: IP) and the second a SAP broadcast packet (Type: Raw). With this
information, you can determine the workstation from the source IP address or the source MAC
address of the packet.
LAN Packet Which Triggered Last Call: (Type IP)
45 00 00 3C 02 12 00 00 3B 01 36 49 00 00 00 00 C0 44 87 22 08 00 62 2B 20 04 00
00 00 08 A9 D0 C0 44 87 22 00 01 02 03 04 05 06 07 08 09 0A 0B
LAN Packet Which Triggered Last Call: (Type Raw)
FF FF 00 22 00 11 00 00 00 00 FF FF FF FF FF FF 04 52 00 00 00 00 00 40 95 90 04
B9 40 08 00 03 02 78 01 A5 A5 A5 A5 A5 A5 A5 A5
Source IP Address
Source MAC Address
